Dimension
|
:
|
130mm
x 67mm (4.5” x 2.6” x
1.6”) |
|
Weight
|
: |
450
gms. (With Batteries) |
|
Accessories
|
:
|
Standard: -
Carring Case Batt. Charger
Optional:
- Aspirator adaptor |
|
Measurement Range
|
: |
0
– 5000 ppm OR ( 0 – 5% V/V.) |
|
Display |
: |
Liquid
Crystal Display (LCD) |
|
Standard
Alarm Levels
|
: |
At
TLV |
|
Optional
Alarm Levels |
:
|
As
per specification |
|
Alarm
Indication |
:
|
Pulsating
/ Continuous red LED with
audible, 90 db at 1 Meter |
|
Battery
|
: |
Standard:
Rechargeable 4 x AA cells
Optional:
Disposable |
|
Battery
Life |
: |
12
– 15 hrs. Continuous |
|
Oper.
Temperature |
: |
-10
deg C to 50 deg C. (14 deg F
to 122 deg F) |
|
Humidity |
: |
0
– 95% RH Non - Condensing |
|
Accuracy |
: |
+/-
10 of Test Gas Concentration |
|
Resolution |
: |
1ppm
OR ( 1% V/V.) |
|
Response
Time |
: |
T90
< 20 Sec. |
|
Setting |
: |
Zero/
Span accessible from outside |
|
Sensor
Type |
: |
Infra
Red (NDIR – Non Dispersive
Infra Red) |
|
Sensor
Life |
: |
Max.
5 to 8 years (in fresh air) |
Tested for Intrinsically safe as per IS
5780-2002{IEC-60079-11(1999)}
