Dimension
|
:
|
130mm
x 67mm (4.5” x 2.6” x 1.6”) |
|
Weight
|
: |
450
gms. (With Batteries)
|
|
Accessories
|
:
|
Standard:
- Carring Case Batt. Charger
Optional: - Aspirator adaptor |
|
Measurement Range
|
: |
0
– 25% vol. or 0 – 100% vol |
|
Display |
: |
Liquid
Crystal Display (LCD)
|
|
Standard
Alarm Levels
|
: |
LO
– 19.5% HI – 22.5% |
|
Optional
Alarm Levels |
:
|
As
per specification |
|
Alarm
Indication |
:
|
Pulsating
/ Continuous red LED with
audible, 90 db at 1 Meter |
|
Battery
|
: |
Standard: Rechargeable 4
x AA cells
Optional: Disposable |
|
Battery
Life |
: |
12
– 15 hrs. Continuous |
|
Oper.
Temperature |
: |
-10
deg C to 50 deg C. (14 deg F
to 122 deg F) |
|
Humidity |
: |
0
– 95% RH Non - Condensing |
|
Resolution |
: |
0.1% |
|
Response
Time |
: |
T95
< 15 Sec. |
|
Setting |
: |
Zero/
Span accessible from outside |
|
Sensor
Type |
: |
Electrochemical |
|
Sensor
Life |
: |
2
to 3 years (in fresh air) |
Tested for Intrinsically safe as per IS
5780-2002{IEC-60079-11(1999)}
